Crawler skid steer loader YZ-S370
S370 Skid Steer Loader: Versatile Power for Diverse Scenarios
Introducing the S370 Skid Steer Loader, designed for excellent performance in small - scale, variable - task scenarios. Its compact and flexible structure, along with practical functions, makes it highly efficient for infrastructure construction, industrial use, dock loading and unloading, etc. Equipped with user - friendly operation features and reliable components, it sets a new standard for productivity in relevant operations.
Key Features
Simple and Easy Operation
Intuitive control layout, convenient for quick mastery and operation
Reduces operator learning cost, suitable for different skill levels
Counterbalance Arm Design
Effectively improves the machine's balance during operation
Enhances stability when handling materials or working on uneven ground
Dual - pump System
Provides stable and sufficient hydraulic power
Ensures smooth operation of working devices, improving work efficiency
Compact and Flexible
Small size, suitable for narrow spaces such as alleys, barns
Easy to maneuver, can flexibly turn and operate in limited areas
Durable and Rust - proof
Adopts high - quality thick steel plate and plastic spraying process
Enhances the machine's durability and corrosion resistance, extending service life
360 - degree Rotation
360 - degree free rotation of the body, convenient for operation in various directions
Smart body design, bringing more convenience for outdoor work
Technical Specifications
| Parameter | S370 |
|---|---|
| Operating weight | 1020kg |
| Bucket capacity | 0.27m³ |
| Climbing ability | 25° |
| Maximum breakout force | 3.5KN |
| Rated load | 350kg |
| Tire size | 18×8.5 - 8 |
| Travel speed | 0 - 5.5km/h |
| Three - item sum of work | 8s |
| Working system pressure | 17.5MPa |
| Maximum dumping height | 1935mm |
| Max loading height | 1579mm |
| Max operating height | 2415mm |
| Max height bucket dump angle | 47° |
| Min height | 1208mm |
| Tail length | 500mm |
| Ground clearance | 170mm |
| Wheelbase | 630mm |
| Diveall | 495mm |
| Overall dimensions | 2138×1070×1508mm |
| Length excluding bucket | 1585mm |
| Fire model | 192F - 5 |
| Engine | 186F |
| Rated power | 6.6kw |
| Cylinder | 1 |
| Intake method | Naturally Aspirated |
| Emission standard | EPA EUROV |
| Fuel tank capacity | 6.5L |
Why Choose S370?
Compact and Flexible: Small size, can work in narrow spaces such as alleys and barns
Easy to Operate: Simple operation, low learning cost, suitable for different operators
Good Balance: Counterbalance arm design ensures stable operation
Durable and Reliable: High - quality materials and processes, long service life
Versatile Application: Applicable to infrastructure construction, industrial use, dock loading and unloading and other scenarios
The S370 Skid Steer Loader integrates compactness, flexibility and practical performance. With its user - friendly design, reliable components and versatile application, this machine provides efficient operation solutions for infrastructure construction, industrial and material handling and other fields. Experience the practical engineering design that makes the S370 an ideal choice for small - scale and variable - task workplaces.
