Crawler skid steer loader YZ-V1000
- Ultra-Narrow 960mm Body
- 200mm Rough-Terrain Clearance
- Dual Engine Options
- 24-Hour Water-Cooled Operation
- EPA & EURO V Certified
- Italian HANSA Hydraulic System
- Bucket Float Function
- Internal Hydraulic Line Protection
- Automatic Safety Lock
- 4-Point Trailer Hook
- Single-Hand Pilot Control
- Shock-Absorbing Anti-Slip Platform
- LCD Touch Monitoring
- Quick-Change Oil Filter Access
- Vertical Lift Design
- Welded Debris-Shedding Frame
- Pressure-Spring Trailer Hook
V1000 Skid Steer Loader: Precision Power for Demanding Environments
Introducing the V1000 Skid Steer Loader, engineered for exceptional performance in confined spaces and challenging terrains. With its compact design and powerful capabilities, the V1000 delivers superior efficiency for construction, landscaping, and material handling operations. Featuring advanced safety systems and premium components, this loader redefines productivity standards.
Key Features
Premium Power Options
Choice of Yanmar 3TNV80F (17.8kW) or Kubota D1105 (18.5kW) diesel engines
Compliant with EPA & EURO V emission standards
Water-cooled system enables continuous 24-hour operation
Advanced Hydraulic System
Italian HANSA closed-loop hydraulic system for optimal performance
Hydraulic lines routed inside loader arms for maximum protection
Pressure-release type auxiliary hydraulic couplers
Precision Control & Safety
Pilot control handle for single-handed, precise operation
Automatic safety lock engages when operator leaves the platform
Trailer safety hook with four-point positioning system
Optimized Design
Compact 960mm body width for superior maneuverability
Vertical lift arms with 2140mm pin height for high-side truck loading
200mm ground clearance for rough terrain operation
Operator Comfort
Shock-absorbing anti-slip standing board
LCD touch screen monitoring oil quantity, temperature and pressure
12V power port and cigarette lighter for convenience
Technical Specifications
| Parameter | Yanmar 3TNV80F | Kubota D1105 |
|---|---|---|
| Rated Power | 17.8 kW | 18.5 kW |
| Displacement | 1267 CC | 1226 CC |
| Cylinders | 3 | |
| Fuel Tank Capacity | 40 L | |
| Operating Weight | 1658 kg (3655 Lb) | |
| Bucket Capacity | 0.19 m³ (6.71 ft³) | |
| Max Lifting Force | 650 kg (1433 Lb) | |
| Travel Speed | 0-4.5 km/h (0-2.8 mph) | |
| Ground Clearance | 200 mm | |
Why Choose V1000?
Nimble Performance: 960mm width enables operation in tightest spaces
Premium Hydraulics: Italian HANSA system ensures smooth, responsive operation
Advanced Safety: Auto-lock system and four-point trailer hook for secure operation
Continuous Operation: Water-cooled engine supports 24-hour work cycles
Operator Focused: Pilot controls and LCD monitoring enhance user experience
The V1000 Skid Steer Loader combines compact agility with industrial-strength performance. With its premium components, advanced safety systems, and operator-friendly design, this machine delivers unmatched productivity in construction, agriculture, and material handling applications. Experience the precision engineering that makes the V1000 the ultimate solution for demanding worksites.
