Skid Steer Angle Sweeper: Sweep and Windrow in One Pass
The TOVISEN Angle Sweeper is a hydraulic rotary broom skid steer attachment for construction site cleanup, parking lots, and municipal walkways. The 1050 mm brush clears dirt, dried mud, and light snow in a single pass, and the hydraulic angling sweeps debris into a windrow without the operator ever repositioning the machine.

Key Features
±25° Hydraulic Angling from the Cab: Angle the brush housing left or right up to 25° on the fly and sweep debris into a windrow along the curb or wall — no stopping, no repositioning, and the windrow does the collection for you.
1050 mm Width with a 500 mm Brush: The 500 mm diameter brush keeps full bristle contact through its 1050 mm sweeping path, so one pass finishes the job instead of overlapping passes — and OEM widths from 1000 to 1800 mm match larger carriers.
Wafer-Style Brush Rings, Sectional Replacement: The brush is built from wafer-style rings, so worn sections get replaced individually instead of re-wrapping the whole core — the running cost over a season of abrasive construction dust drops accordingly.
High-Torque Motor That Holds Speed Under Load: The hydraulic drive keeps brush rotation consistent when the bristles hit heavy debris, which is what separates actual sweeping from just flicking dirt around; motor configurations for high-flow and standard-flow loaders are both available through OEM.
Universal Quick Attach, 145 kg: Mounts on standard quick-attach loaders including the TOVISEN skid steer loaders, and at 145 kg with a 1245 × 1010 × 580 mm frame it ships as a single compact unit.
Customizable Sweeping Solutions
As a specialized manufacturer, TOVISEN offers complete OEM & ODM customization to adapt our sweepers to your specific fleet and environmental conditions:
✅ Bristle Material: Choice of pure poly, wire-poly mix, or all-steel bristles.
✅ Custom Widths: Tailored sweeping widths from 1000 mm to 1800 mm.
✅ Color & Branding: Fleet-matched paint colors and laser-cut branding.
✅ Hydraulic Fittings: Custom motor configurations for high-flow or standard-flow loaders.
Technical Specifications
| Parameter Item | Detailed Specification |
|---|---|
| Sweeping Width | 1050 mm |
| Brush Diameter | 500 mm |
| Swing Angle (Left/Right) | ±25° |
| Overall Dimensions | 1245 × 1010 × 580 mm |
| Unit Weight | 145 kg |
| Mounting Type | Standard Universal Quick Attach |
FAQ
Which bristle material should I choose?
Pure poly bristles are the safe choice for finished surfaces like parking lots and walkways; a wire-poly mix handles general construction dust and packed mud with more scrubbing force; all-steel bristles suit heavy scraping work and snow crust on rough pavement. All three are available through the OEM bristle options, so you can match the material to the surface your market actually sweeps.
Can it clear snow?
Yes — light and freshly fallen snow, where the brush sweeps it off the surface the same way it moves loose debris. For deep or compacted ice layers, a dedicated snow blade or blower is the right tool, and being upfront about that avoids winter performance disputes with your customers.
Will it run on my loader's hydraulic flow?
Motor configurations for both high-flow and standard-flow loaders are available through OEM customization. Not sure which category your machine falls into? Our skid steer hydraulic attachments guide explains how to check, or send your loader model with the inquiry and we will match the motor before quoting.
